HIGH-RESOLUTION GEOSPACIAL MAPPING & IMAGING SYSTEM

The NSP-5 EO/IR is an electro-optical infrared sensor capable of integrating with low SWaP payloads.

nsp-5-eoirgrey

Electro-optical infrared imaging is an important part of a complete ISR sensor package. The NSP-5 EO/IR specializes in geospatial mapping, which takes high-resolution still imagery that can be orthorectified and stitched together to provide updated maps of an imaged area. The NSP-5 EO/IR’s ability to rotate from horizon to horizon and capture off-nadir still imagery adds versatility to how it is used in-flight. Get the imagery you need so that you can stay up to date on necessary maps and make accurate and informed decisions.

integrationblack

SIMPLIFY INTEGRATION

The NSP-5 EO/IR is designed as a standalone sensor payload or complement to existing payloads. It is quickly and easily attached to an aircraft’s wing or fuselage.

platformsblack

BIG PERFORMANCE, SMALL SWAP

With the low size, weight, and power of the NSP-5 EO/IR, smaller platforms have access to advanced capabilities that previously have not been available.

familyblack

PART OF THE FAMILY

NSP-5 EO/IR shares the same mounting system as the other NSP-5 Products. Any NSP-5 pod can be swapped quickly and easily to meet mission needs and available resources.

increaseblack

INCREASE CAPABILITIES

Add the NSP-5 EO/IR to any aircraft will add geospatial mapping, electro-optical, and infrared imaging in the convenient and compact NSP-5 family format.

MULTI-INT CAPABILITIES

Every year, technology continues to shrink in size yet grow in capability. World-class imaging radar technology is no different. While being the smallest of its kind, the NSP-5 EO/IR packs some very powerful capabilities.

ELECTRO-OPTICAL

ELECTRO-OPTICAL

EO imagery is capable of capturing extremely high-resolution photographic stills from high altitudes.

INFRARED

INFRARED

IR is capable of detecting infrared radiation and compiling the information into a map of high-resolution thermal detects.

GEOSPATIAL MAPPING

GEOSPATIAL MAPPING

Geospatial mapping uses electro-optical imaging to take orthorectified, photographic imagery and stitches it to form a map.

SIZE WEIGHT AND POWER

Dimensions Diameter: 5.48 in (13.9cm)
Length: 43.2 in (109.7 cm)
Height: 8.5 in (21.5 cm)
Weight 18 lbs (8.3 kg)
Power 24 W
Supply Voltage 24 – 48 W

KEY SPECIFICATIONS

Standoff Range 1 – 3 km
EO Resolution 18 MP
EO Field of View (FOV) 4.26° x 6.38°
IR Resolution .3 MP
IR Field of View (FOV) 4.4° x 3.3°
Capabilities; Electro-Optical, Infrared

GET THE IMAGERY YOU NEED TO MAKE ACCURATE AND INFORMED DECISIONS.

The more you can see, the more you know; and the more you know, the more you succeed. Let’s put our geospatial intelligence system with advanced capabilities on your platform.
